Product Name | Wall-Smart for KA8 |
Product No. (Black bezel) | 027-1-498-BL |
Product No. (White Bezel) | 027-1-498-WH |
Product No. (Unpainted bezel) | 027-1-498-WO |
Type | Retrofit - With speaker and mic grills. |
Surface | Nearly flush with the wall (4mm/0.16") thick on-wall bezel |
Installation | Wall board thickness 10mm (0.39") up to 21mm (0.83"). For boards up to 32mm (1.25") thick, reinstall cam latches upside down. |
POE to USB power adapter | The installer should connect the all mount to an IEEE 802.3at POE+ power source via CAT6 cable and RJ45 connector. |
Dimensions (W/H/D) | 367mm (14.45")/ 254.9mm (10.04")/ 40mm (1.58”) |
